Last minute "Make Shift" Trade Show Booth design
We only had 3 weeks to build a new booth out of old parts that have been sitting in storage for 6 years.

Solidworks Framing Model
After doing inventory of all modular pieces. I quickly created this model in solid works.

JWEI Tradeshow Booth - Right Perspective
Our only opportunity to spice things up was through prints that we could order through a local print shop

JWEI Tradeshow Booth - Left Perspective
Idea was to get new graphic prints to hang over the Modular system that featured the products we were selling at the show

JWEI Tradeshow Booth - Right View
We wanted to create space within the small 20x20 booth that would allow distributors to hold meetings with local store owners

JWEI Tradeshow Booth - Left View
We wanted to create space within the small 20x20 booth that would allow distributors to hold meetings with local store owners

JWEI Tradeshow Booth - Top View
We wanted to create space within the small 20x20 booth that would allow distributors to hold meetings with local store owners

Wismec-Banner
One of my Graphic Prints featuring the Wismec Active Speaker Mod

Joyetech-Banner
Graphic Prints featuring the Joyetech Espion Infinite Mod

Eleaf-Banner
Graphic Prints featuring the Eleaf iJust 21700 Mod

Right-side-banner
Graphic Prints featuring the CB-80 and Motus Mod

Left-Side-Banner
Graphic Prints featuring the Lexicon and IStick Pico Mod

Solidworks BOM
After all prints were ordered I created a BOM and got busy doing a test build of the Booths frame work

Framework Test fit
IT WORKED!!

Framework Test fit
IT WORKED!!

Booth In Action (it was break time)
Its not as clean as my Solidworks/Keyshot model but the tradeshow was a huge success

Vaperev Trade Show Booth Design ECC Expo 2014
Developed the graphic prints for the meeting area booth and full design of the circle bar for retail sales

Vaperev Trade Show Booth Design ECC Expo 2014
Developed the graphic prints for the meeting area booth and full design of the circle bar for retail sales

Vaperev Trade Show Booth Design ECC Expo 2014
Circle Bar Retail Booth that fit within the large common area that allowed crowd flow from one vendor to another

Vaperev Trade Show Booth Design ECC Expo 2014
Circle Bar Retail Booth that fit within the large common area that allowed crowd flow from one vendor to another

Vaperev Trade Show Booth Design ECC Expo 2014
Circle Bar Retail Booth that fit within the large common area that allowed crowd flow from one vendor to another

Vaperev Trade Show Booth Design ECC Expo 2014
Circle Bar Retail Booth that fit within the large common area that allowed crowd flow from one vendor to another

Vaperev Trade Show Booth Design ECC Expo 2014
Circle Bar Retail Booth that fit within the large common area that allowed crowd flow from one vendor to another

Graphic Design
Graphic Design Layouts for Multiple Brands
